• STAGE ONE XB SUBWOOFER
1 1

Electrotec Audio

STAGE ONE XB SUBWOOFER

$1,399.00 USD
$1,399.00 USD

TRY IT FOR 60 DAYS RISK FREE

2 YEAR WARRANTY INCLUDED
    STAGE ONE XB SUBWOOFER

    MEET THE XB SUBWOOFER.

    THE WORLD’S FIRST COMPACT DUAL 10-INCH WIRELESS BATTERY SUB-WOOFER SYSTEM. THE PERFECT COMPANION TO THE STAGE ONE AND FRIENDLY TO OTHER SKAA ENABLED SPEAKERS OR TRADITIONAL WALL POWERED SPEAKERS. THE STAGE ONE XB PACKS A PUNCH WHILE PROVIDING CLEAN BASS YOU CAN FEEL.

    FEATURES:

    • 400 WATTS RMS
    • DUAL HOT-SWAPPABLE BATTERIES
    • SKAA WIRELESS ENABLED
    • COMBO XLR - 1/4 INPUT AND XLR OUTPUT
    • 3.5MM INPUT AND OUTPUT
    • LOW PASS FILTER & HIGH PASS FILTER
    • PHASING
    • ROUTING OPTION FOR BOTH LPF & HPF

    VERSATILE, POWERFUL AND BATTERY POWERED USING THE SAME BATTERY TECHNOLOGY AS THE STAGE ONE.

    TRY RISK FREE FOR 60 DAYS!

    TECH SPECS

    FEATURES
    • LPF (LOW PASS FILTER)
    • PHASE
    • ROUTING (LEFT,RIGHT,MONO)
    • XLR HPF (HIGH PASS FILTER)
    • XLR ROUTING (LEFT,RIGHT,MONO)
    INPUTS / OUTPUTS

    INPUTS:

    • SKAA & SKAA PRO WIRELESS
    • COMBI XLR & 1/4 INCH JACK
    • 3.5MM STEREO INPUT

    OUTPUTS:

    • XLR OUT
    • 3.5MM STEREO OUTPUT
    AMPLIFICATION

    2X 200W RMS INFINEON MERUS AMP FOR EACH WOOFER
    DRIVERS / FREQUENCY RESPONSE

    DRIVERS:

    1 X 10" 2 Ohm ELECTROTEC DESIGNED WOOFER

    FREQUENCY RESPONSE:

    Reference: 997 Hz at 1W, AES17 LPF 22 Hz - 200 Hz +/- 3 dB
    THD+N (Bi-Amp Out) 1W, 20 Hz – 200 Hz, AES17 LPF < 0.05 %
    SNR A-Weighted (Bi-Amp Out) Reference: 75Hz at 1W, AES17 LPF > 82 dB
    Digital Resolution (SKAA) 48 kSamples/s, 16 bit

    SPL 126
    WIRELESS / SKAA

    RF:

    RF POWER +18dBm
    ANTENNA TYPE: FE

    SKAA:

    SKAA STANDARD COMPATIBILITY, SKAA OS 2.1 AND LATER
    SKAA LATENCY: 36.71ms +/_ 1.5 samples, 19.39ms +/- 1.5 samples (PRO MODE)
    SKAA MAX RECEIVERS 4 WITH SKAA SOURCE OR 2 WITH SKAA PRO SOURCE

    BATTERY SPECIFICATIONS

    114Wh, 22V at 5200mAh
    BATTERY MANAGEMENT ONBOARD BATTERY
    POWER SUPPLY 100-240 VAC, OUTPUT 26V 125W, 2 AMP MAX
    100+ HOURS AT MID VOLUME (USING BOTH BATTERIES_
    8+ HOURS AT MAX VOLUME (USING BOTH BATTERIES)
    2.5 HOUR RAPID CHARGE TO FULL PER BATTERY
    CABINET

    MATERIAL:

    PHENOLIC & VINYL COATED BIRCH

    DIMENSIONS:

    15.75 X 14.5 X 26.25 INCHES

    WEIGHT:

    44 LBS WITH BATTERIES
